SQ Series

SQ Series

Thanks to their important features, SQ pumps are the ideal solution for the carriage of waters coming from cleaners, sewing systems, zootechnic farms, slaughter-houses, foundries and for irrigation in agricultural field. Applicable in fishing industry, paper mills and in civil and industrial plants. The pumps adopt open single-blade impeller which allows free passage of suspended parts and high performance.

OPERATING CONDITIONS


• Liquid temperature 35°C (according to EN 60335-2-41) up to 50°C (for other uses)

• Submersion depth 20 mt (with a cable of the appropriate length)

• Liquid PH from 4 to 10

• Continuous duty with completely submersed pump

• Liquid density 1,2 Kg/dm3
